- Carbon Reproductions 2017 OE Style Spoiler
Carbon Reproductions
Carbon Reproductions 2017 OE Style Spoiler
2013+ FR-S / BRZ / 86
OE style with a sport carbon fiber look.Details
2017+ OEM Style Carbon Fiber Spoiler
Toyota and Subaru recently debuted facelifted models. The premium versions (TRD / Limited) featured a new OEM spoiler with black center portion and paint matched ends. This Carbon Reproductions model wraps a gloss carbon fiber layer over every surface in view.
OE design meets beautiful carbon fiber. Includes pre-mounted 3M and bolts.
Installation Instructions
These premium spoilers attach with a combination of 3M tape and 4 bolts.
Step 1
Tape off the corners of your rear decklid with painter's tape. You must tape a large enough portion to trace the pedestal.
Center the spoiler on the trunk. Make sure the gaps between the pedestal and the outer edge of the trunk are even on both sides. There are two curves on the back side of the trunk. Make sure that the trail edge of the pedestal aligns with the TOP curve and not the bottom curve.
Step 2
Start on one side and trace around the pedestal enough so that you can position the 3M plastic backing seen in step 3. Upper mark, lower mark, and marks on both sides should be enough. Repeat for the other side.
Remove the 3M backing plastic from each pedestal, noting which side they came from. Store the spoiler in a safe area for this short time so that it does not become damaged nor does anything get on the bottom of the 3M tape.
Step 3
Align the plastic backing with the text facing downwards so you can locate the area where the bolt is inserted. Place a circle in the middle of the square as a guide for drilling.
Step 4
Use the templates you just made to drill a pilot hole through both the top of the trunk. Then use a drill bit similar in size to the bolt to go through the top of the trunk and the bottom layer. Once you have done this, you will need to use a hole saw bit to enlarge the hole on the inside of the trunk. This is the only way you can tighten the bolt. It has to be wide enough to insert a socket.
Verify that all bolts can pass through the holes and all bottom holes are wide enough Once you have done this for all 4 holes (2 per side), you can remove the painter's tape and remove the remaining 3M plastic backing off the spoiler (center).
Step 5
Bolt the wing to the vehicle. You can use silicon gasket maker around the holes as a precautionary step to prevent moisture intrusion.
Additional Information
Installation Instructions None Additional Warranty Information None
Carbon Reproductions 2017 OE Style Spoiler / 86OECB-S Fits
Scion FR-S Base2013 Scion FR-S Base2014 Scion FR-S Base2015 Scion FR-S BaseSubaru BRZ Limited2013 Subaru BRZ Limited2014 Subaru BRZ Limited2017 Subaru BRZ Limited2018 Subaru BRZ LimitedPremium2013 Subaru BRZ Premium2017 Subaru BRZ PremiumToyota 86 Base2017 Toyota 86 Base2018 Toyota 86 BaseGT2018 Toyota 86 GT0 customer reviews
Average ratingEase of Installation Fit / Quality Overall Satisfaction -
Very Nice
I have a 2019 BRZ, and the pre-drilled holes in this spoiler somewhat match up with the ones with the stock spoiler. They were about 1/2 - 1/3 inch off. The quality is very nice and weighs quite a bit less than stock. The 3M tape, once bonded, is super strong.
-
Great Spoiler for practical uses and as a daily driver
only problem I had was making the holes in the trunk of the FR-S, but overall everything else was simple, like the measurements/ alignments (was only like 1/4 inch off) and putting it on
